Vanadium is a white-silver metal that is most commonly found in the aerospace, medical, and automotive industries. At Fine Metals, we offer vanadium in a variety of purities and forms.
General Properties
Symbol: V
Atomic Number: 23
Atomic Weight: 50.9415
Density: 6.11 gm/cc
Melting Point: 1890 oC
Boiling Point: 3380 oC
Thermal Conductivity: 0.307 W/cm/K @ 298.2 K
Electrical Resistivity: 25.4 microhm-cm @ 20 oC
Electronegativity: 1.6 Paulings
Specific Heat: 0.116 Cal/g/K @ 25 oC
Heat of Vaporization: 106 K-Cal/gm atom at 3380 oC
Heat of Fusion: 4.20 Cal/gm mole
Linear Coefficient of Expansion: 9.7 x 10-6 @ 20 oC
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Width |
Length |
|
.125″ |
.125″ |
.125″ |
|
.25″ |
.25″ |
.25″ |
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Diameter |
|
.001″ to .004″ |
.5″ to 2″ maximum |
|
.005″ to .010″ |
.5″ to 6″ maximum |
|
.011″ to .125″ |
.5″ to 6″ maximum |
|
.126″ to .200″ |
.5″ to 7″ maximum |
|
.220″ to .325″ |
.5″ to 12″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Width |
Length |
|
.001″ to .002″ |
up to 2″ |
1″ to 8″ maximum |
|
.003″ to .004″ |
up to 4″ |
1″ to 8″ maximum |
|
.005″ to .009″ |
up to 4″ |
1″ to 12″ maximum |
|
.010″ to .020″ |
up to 6″ |
1″ to 20″ maximum |
|
.022″ to .030″ |
up to 4″ |
1″ to 20″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Diameter |
Length |
|
.040″ |
.040″ to 1″ |
|
.062″ |
.062″ to 1″ |
|
.070″ |
.070″ to 1″ |
|
.080″ |
.080″ to 1″ |
|
.085″ |
.085″ to 1″ |
|
.095″ |
.095″ to 1″ |
|
.125″ |
.125″ to 1″ |
|
.236″ |
.236″ to 1″ |
|
.250″ |
.250″ to 1″ |
|
.375″ |
.375″ to 1″ |
Our standard tolerances for pellets are +/- .005″ diameter and +/-.020″ length.
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Width |
Length |
|
.030″ to .125″ |
up to 5″ |
1″ to 20″ maximum |
|
.130″ to .250″ |
up to 6″ |
1″ to 16″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Diameter |
Length |
|
.020″ to .062″ |
up to 72″ maximum |
|
.065″ to .265″ |
up to 96″ maximum |
|
.275″ to .50″ |
up to 72″ maximum |
|
.550″ to .750″ |
up to 36″ maximum |
|
.800″ to 1″ |
up to 24″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
We can provide starter sources in a variety of sizes. Please inquire for specific availability, price, and delivery.
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Width |
Length |
|
.001″ to .004″ |
.5″ to 2″ |
1″ to 8″ maximum |
|
.005″ to .040″ |
.5″ to 2″ |
1″ to 20″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Diameter |
|
.001″ to .003″ |
.5″ to 2″ maximum |
|
.004″ to .008″ |
.5″ to 4″ maximum |
|
.009″ to .040″ |
.5″ to 6″ maximum |
|
.045″ to .225″ |
.5″ to 7″ maximum |
|
.235″ to .300″ |
.5″ to 8″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Thickness |
Width |
Length |
|
.010″ to .125″ |
up to 5″ |
1″ to 20″ maximum |
|
.130″ to .250″ |
up to 6″ |
1″ to 16″ maximum |
Inquire about custom sizing and/or metals or alloys not listed.
|
Diameter |
Length |
|
.004″ to .010″ |
1′ to 1000′ maximum |
|
.012″ to .040″ |
1′ to 500′ maximum |
|
.042″ to .080″ |
1′ to 250′ maximum |
|
.082″ to .125″ |
1′ to 100′ maximum |
